Deye Microinverter SUN-M80G3-EU-Q0 800W with wifi Single Phase 2 Mppt Grid-tie EU Version Micro Solar inverter
Specification
SUN-M60/80/100G3-EU-Q0 is a new generation grid-connected micro inverter with intelligent networking and monitoring system to ensure maximum efficiency. The SUN-M60/80/100G3-EU-Q0 is optimized to efficiently accommodate today's high output photovoltaic modules with up to 500W output and dual MPPT. At the same time, it supports fast shutdown applications to ensure the safety of your investment.
| Model |
SUN-M60G3-EU-Q0
|
SUN-M80G3-EU-Q0
|
SUN-M100G3-EU-Q0
|
|||
| Input Data (DC) | ||||||
| Recommended input Power (STC) | 210-400W (2 Pieces) | 210-500W (2 Pieces) | 210-600W (2 Pieces) | |||
| Maximum input DC Voltag | 60V | |||||
| MPPT Voltage Range | 25-55V | |||||
| Operating DC Voltage Range | 20-60V | |||||
| Max. DC Short Circuit Current | 2x19.5A | |||||
| Max input Current | 2x13A | |||||
| Number of MPPT/Strings per MPPT | 2/1 | |||||
| Output Data (AC) | ||||||
| Rated output Power | 600W | |||||
| Rated output Current | 2.7A | 2.6A | 3.6A | 3.5A | 4.5A | 4.4A |
| Nominal Voltage/Range (this may vary with grid standards) | 220V/ 0.85Un-1.1Un | 230V/ 0.85Un-1.1Un | 220V/ 0.85Un-1.1Un | 230V/ 0.85Un-1.1Un | 220V/ 0.85Un-1.1Un | 230V/ 0.85Un-1.1Un |
| Nominal Frequency/Range | 50/60Hz | |||||
| Extended Frequency/Range | 45-55Hz/55-65Hz | |||||
| PowerFactor | >0.99 | |||||
| Maximum units per branch | 8 | 6 | 5 | |||
| Efficiency | ||||||
| CECWeighted Efficiency | 95% | |||||
| Peak Inverter Efficiency | 96.5% | |||||
| Static MPPT Efficiency | 99% | |||||
| Night Time Power Consumption | 50mW | |||||
| Mechanical Data | ||||||
| Ambient Temperature Range | -40-65°C | |||||
| Size (mm) | 212Wx230Hx40D (Without mounting bracket and cable) | |||||
| Weight(kg) | 3.5 | |||||
| Cooling | Natural cooling | |||||
| Enclosure Environmental Rating | IP67 | |||||
| Features | ||||||
| Compatibility | Compatible with 60-72 cell PV modules | |||||
| Communication | Power line/WIFI/Zigbee | |||||
| Grid Connection Standard | ENS0549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116, RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547 | |||||
| Safety EMC/Standard | UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3 | |||||
| Warranty | 10 years | |||||
Product Features
- Zigbee or WIFI communication
- Support reactive power compensation
- Quick shutdown function
- IP67 protection level, 10-year warranty
- 2 MPP tracker, module-level monitoring
